JVC XV-SA600BK Service Manual

XV-SA600BK/XV-SA602SL
3-17
Item
Parts number Parts name Area
Electrical parts list (Surround audio board)
Remarks
Block No. 03
A
R 928 QRE141J-561Y C RESISTOR 560 5% 1/4W
R 929 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 930 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 931 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 932 QRE141J-183Y C RESISTOR
18K 5% 1/4W
R 933 QRE141J-102Y C RESISTOR
1.0K 5% 1/4
W
R 934 QRE141J-102Y C RESISTOR
1.0K 5% 1/4
W
R 935 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 936 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 937 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 938 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 939 QRA14CF-7500Y MF RESISTOR 75 1/4W
R 940 QRA14CF-7500Y MF RESISTOR 75 1/4W
R 943 QRA14CF-7500Y MF RESISTOR 75 1/4W
R 944 QRA14CF-7500Y MF RESISTOR
75 1/4W
R 945 QRE141J-362Y C RESISTOR
3.6K 5% 1/4
W
R 946 QRE141J-362Y C RESISTOR
3.6K 5% 1/4
W
R 947 QRA14CF-3602Y MF RESISTOR
36 1/4W
R 948 QRA14CF-3602Y MF RESISTOR
36 1/4W
R 949 QRA14CF-1601Y MF RESISTOR 16 1/4W
R 950 QRA14CF-1601Y MF RESISTOR 16 1/4W
R 951 QRA14CF-1802Y MF RESISTOR 18 1/4W
R 954 QRA14CF-1802Y MF RESISTOR 18 1/4W
R 957 QRE141J-303Y C RESISTOR
30K 5% 1/4W
R 958 QRE141J-303Y C RESISTOR
30K 5% 1/4W
R 959 QRE141J-303Y C RESISTOR
30K 5% 1/4W
R 962 QRE141J-470Y C RESISTOR
47 5% 1/4W
R 966 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 967 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 968 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 970 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 971 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 972 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 973 QRE141J-100Y C RESISTOR
10 5% 1/4W
R 974 QRE141J-560Y C RESISTOR
56 5% 1/4W
R 975 QRE141J-470Y C RESISTOR
47 5% 1/4W
R 976 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 977 QRE141J-332Y C RESISTOR
3.3K 5% 1/4
W
R 980 QRE141J-470Y C RESISTOR 47 5% 1/4W
R 981 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 982 QRA14CF-1802Y MF RESISTOR 18 1/4W
R 983 QRE141J-272Y C RESISTOR 2.7K 5% 1/4
W
R 984 QRE141J-272Y C RESISTOR
2.7K 5% 1/4
W
R 985 QRA14CF-1802Y MF RESISTOR
18 1/4W
R1825 QRE141J-272Y C RESISTOR
2.7K 5% 1/4
W
R1826 QRE141J-272Y C RESISTOR
2.7K 5% 1/4
W
R1845 QRE141J-272Y C RESISTOR
2.7K 5% 1/4
W
R1846 QRE141J-272Y C RESISTOR
2.7K 5% 1/4
W
SP813 VYH7653-001 IC HOLDER
SP823 VYH7653-001 IC HOLDER
