1.2 Overall description
The MAC motor is available many different sizes: MAC050, MAC95, MAC140, MAC141-
A, MAC141-F, MAC400, MAC800, MAC1200, MAC1500, MAC3000 and MAC4500
with continuous power ratings from 46W to 4500W. The basic functions and I/O features
are the same for all models.
Basic
Motor Type
Continuous
Torque
Peak
Torque
Power
(cont.)
Nom.
Speed
Flange Total
length
MAC50
0.11 Nm
(15.58 oz-in)
0.32Nm
(45.3 oz-in)
46 Watt 4000 RPM
NEMA23
57x57mm
(2.3”x2.3”)
111.2 mm,
(4.38”)
MAC95
0.22 Nm
(31.15 oz-in)
0.62 Nm
(87.8 oz-in)
92 Watt 4000 RPM
NEMA23
57x57mm
(2.3”x2.3”)
130.5 mm
(5.13”)
MAC140
0.32 Nm
(45.32 oz-in)
0.9 Nm
(127.45 oz-in)
134 Watt 4000 RPM
NEMA23
57x57mm
(2.3”x2.3”)
152.5 mm
(6”)
MAC141
0.48 Nm
(67.97 oz-in)
1.59 Nm
(225.16 oz-in)
134 Watt 2700 RPM
NEMA23
57x57mm
(2.3”x2.3”)
172.0 mm
(6.77”)
MAC400
1.27 Nm
(180 oz-in)
3.8 Nm
(538.1 oz-in)
400 Watt 3000 RPM
60x60mm
(2.86”x2.86”)
192.0 mm
(7.56”)
MAC402
1.27 Nm
(180 oz-in)
3.8 Nm
(538.1 oz-in)
400 Watt 3000 RPM
60x60mm
(2.86”x2.86”)
192.0 mm
(7.56”)
MAC800
2.38 Nm
(337 oz-in)
7.2 Nm
(1019.6 oz-in)
750 Watt 3000 RPM
80x80mm
(3.14”x3.14”)
175 mm
(6.89”)
MAC1200
3.82 Nm
(538.1 oz-in)
11.46 Nm
(1614 ox-in)
1200 Watt 3000 RPM
80x80mm
(3.14”x3.14”)
226 mm
(8.89”)
MAC1500
4.78 Nm
(676.91 oz-in)
14.33 Nm
(2030.7 oz-in)
1500 Watt 3000 RPM
130x130mm
(5.12”x5.12”)
205.0 mm
(8.07”)
MAC3000
9.56 Nm
(1353.8 oz-in)
28.7 Nm
(4061.4 oz-in)
3000 Watt 3000 RPM
130x130mm
(5.12”x5.12”)
255 mm
(10.04”)
MAC4500
14.30 Nm
(2025.0 oz-in)
52.00 Nm
(7363.7 oz-in)
4500 Watt 3000 RPM
130x130mm
(5.12”x5.12”)
330 mm-
391 mm
(13.0” -
15.5”)
