JVL MAC050 User Manual

450 JVL A/S - User Manual - Integrated Servo Motors MAC050 - 4500
6.15 Cable drawings
6.15.1 WI1000-M12F5T05N - M12 Power cable 5 pin female
6.15.2 WI1028-M8M3STO05 - Safety stop cable.
WI1000-M12F5T05N
M12 shl cable 5 m 5 pin Fem 0°
Power
Date: 04-07-13
JVL A/S
Bregenerødvej 127 DK-3460 Birkerød
Tel: +45 4582 4440
Fax: +45 4582 5550
Version - 1.1
Approved by:
- BVJ
Drawn by:
PCR
LT0233-11
J1
Pin no. J1
Length = 5 m +/-100mm
Text printed on green tube
White
P-
Brown
P+
P+
2
3
Color
Signal name
Type: WI1000-M12F5T05N
M12, 5 pin female connector
Screen
Grey
4
(OptioNs)
1
Blue
Housing
5
5
1
2
4
3
View from front
Black
P-
Length = 5000mm
WI1028_M8M3STO05
Safety stop cabel external
Date: 15-10-13
JVL Industri Elektronik A/S
Blokken 42 • DK-3460 Birkerød
Tel: +45 4582 4440
Fax: +45 4582 5550
JVL Industri Elektronik A/S
Blokken 42 • DK-3460 Birkerød
Tel: +45 4582 4440
Fax: +45 4582 5550
Version - 1.2
Approved by:
_
Drawn by:
PCR
LT0239-12
J1
M8 socket, 3 pin, male
Pin 1
Pin 3
Cable data:
Approvals: UL 94V0
2xAWG28 with screen
on both wire and a
outside screen as well
PVC shield and Screen
Foil shield
3
1
4
Brown
BLack
All Sceen shall be
connected to the
connector house
