16 of 28
Installation
Mounting the Unit
® The unit is an indoor
model and must not be
exposed to rain or water
ingress, or direct sunlight
L Install near a 240V
AC outlet
L We recommend mounting
the unit at eye level
1. Drive a #8 screw into
the wall, leaving approx.
4mm exposed. Use a
toggle bolt or masonry
plug if necessary
2. Hang the unit from the
key at the back, ensuring
it is properly seated
3. Optional: Remove the
terminal cover to add
additional screws through
the holes in the lower
corners for extra stability
To Next Page
