K-Rain KRX6 - Installation; 9 V Battery

6 of 28
9V Battery
1. Open the controller
housing door
2. Locate the 9V
battery snap (b)
® This may be located
under the terminal cover.
If needed, please remove
the cover using the two
tabs (a), feed the battery
snap cable through the
slit and then replace
the terminal cover
3. Connect a 9V battery
to the snap (c)
4. Fit in the compartment
labelled 9VBATTERY
in the lower end
of the housing
a
c
b
Installation
