Adjusting the lock
2" (51 mm) to 2
1
4" (57 mm)
For doors 2" (51 mm) to 2
1
4
" (57 mm)
thick, adjust the lock as follows: (see
figures 4-2 & 4-3)
1. Remove the back plate assembly (AA) by
removing the six back plate screws. One
of the screws may be under the serial
number sticker.
2. Remove the cylindrical drive unit (CC)
from the back plate assembly (AA) by
removing the four Phillips head sems
screws (EE) from the underside of the
back plate.
3. Insert the extra spacer provided in the
accessory pack (item “f” on the
checklist) between the cylindrical drive
unit (CC) and the back plate assembly
(AA).
4. Remount the cylindrical drive unit (CC)
onto the back plate assembly (AA) using
the four 8-32 x
11
16" (17 mm) Phillips
head sems screws provided (item “l” on
checklist).
5. Add a cross pin (item “h” on the
checklist) in position A on the drive shaft
(DD) (see figure 4-3).
6. Remount the back plate assembly (AA)
onto the front lock case.
Warning: Damage may result if the knob
hits against either the wall or the wall stop.
In such a case, ALL warranties are null and
void.
4b
Ajuste de la cerradura
2 pulg. (51 mm) a 2
1
4 pulg. (57 mm)
Para las puertas de 2 pulg. (51 mm) a
2
1
4 pulg. (57 mm) de espesor, ajuste la
cerradura de la manera siguiente (véase
las ilustraciones 4-2 y 4-3):
1. Quite la placa de montaje posterior (AA),
sacando los seis tornillos. Uno de los
tornillos puede ir debajo de la etiqueta con
el número de serie.
2. Saque la unidad cilíndrica (CC) de esa
placa (AA), quitándole los cuatro tornillos
Phillips (EE) de la parte de adentro de la
placa.
3. Inserte el espaciador adicional, que viene
con el juego de accesorios (artículo “f” en
la hoja de verificación), entre la unidad
cilíndrica (CC) y la placa posterior (AA).
4. Vuelva a montar la unidad cilíndrica (CC)
sobre la placa posterior (AA), utilizando
los cuatro tornillos Philips, 8-32 x
11
16 pulg.
(17 mm), provistos (artículo “l” en la hoja
de verificación).
5. Añada un pasador transversal (artículo
“h” en la hoja de verificación) en la
posición A del eje (DD) (véase la
ilustración 4-3).
6. Vuelva a instalar la placa de montaje
posterior (AA) en la caja delantera de la
cerradura.
Advertencia: Si la perilla golpea contra la
pared o el tope de la puerta, puede dañarse.
En tal caso, quedarán anuladas TODAS las
garantías.
PK2280/03/02 Impos. 1/29/03 12:16 PM Page 12
