RFID Installation Instructions Pg 7 of 8
Testing Lock Functionality
Pass a Construction key over the Quantum RFID reader. The green light will flash for five seconds.
Be sure that the green light flashes for five seconds while the exterior lever remains operable. If the
green light does not flash, refer to the table below.
Lock Communication Electronic Function Description
Red and green LEDs flash Time and date not set, use the Hand held and Quantum RFID
nine times simultaneously LPI probe to reset
or for 5 seconds
Yellow LED flashes 12 times Dead bolt is thrown or switch cam is not properly aligned
Yellow LED flashes two times Keycard not allowed OR keycard cancelled by new keycard
Red and green LEDs flash Low battery (contact the SAFLOK service department)
alternately nine times
Yellow and red LEDs flash Bad keycard read or corrupted data (may require new
two times simultaneously keycard) – Error logging to keycard. Hold keycard in front of the
lock reader longer.
Red and yellow LED flashes two times Keycard not read (Key reader may be damaged)
