Kaba SIMPLEX 3000 NARROW STILE - Table of Contents

2
TABLE OF CONTENTS
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
A. Combination Lock Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
B. Mounting Lock to Stile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
C. Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
D. Combination Change Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
E. Resetting an Unknown Combination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Warnings and Cautions
Important: Carefully inspect windows, doorframe, door, etc. to ensure that
the recommended procedures will not cause any damage. Kaba Access
Control’s warranty does not cover damages caused by installation.
Caution: Wear safety glasses when preparing door.
• Combination lock assembly
• Instructions for changing
combination
• Operating instructions
• Warranty card
• DF-59 keys
• Mounting screws 10-24 thd. X 2
1
⁄8"
• Inside trim plate assembly
• Cylinder groove screws #4
self-tapping screw
• Optional cylinder guard (3002
models only)
• Cam stop screw 6–32 thd. X
3
⁄16"
long
PACKAGE CONTENTS
TOOLS REQUIRED FOR INSTALLATION:
• Flat blade screwdrivers (small and medium)
• Phillips head screwdriver (large)
• Tape
• Hammer
• Deburring tool
• Drill (variable speed recommended)
• Center punch
• (
3
⁄32") drill bit
• (
3
⁄8") drill bit
• (
1
⁄8") drill bit
• (
1
⁄4") drill bit
• (
7
⁄8") hole saw
