Kaba Simplex 506 Series User Manual

4
For technical assistance please call
1-800-849-TECH (8324) or 336-725-1331
The 1
1
⁄4” Mortise lock for the Simplex series comes preassembled from the
factory for a left-hand installation. It is field reversible.
Installation Qualifications
These instructions are designed for use by maintenance professionals or lock
installers who are familiar with common safety practices and competent to
perform the steps described. Kaba Access Control is not responsible for
damage,injuryormalfunctionduetoincorrectinstallation.
Outside Unit
Assembly
Outside Lever
Assembly
Mounting
Plate
Mortise Lock
Mortise Faceplate
Strike
Mortise
Spindle
Deadbolt
Thumbturn
Spindle
Bottom
Mounting
Screws
Release/Combination
Change Tool
Inside
Mounting
Plate
Screws
Allen
Wrench
Inside Unit
Assembly
Inside Lever
Top
Mounting Screws
Simplex 1
1
⁄4” Mortise Lock
506x Models
LIT1051_Simplex_506x _Mortise_1012.indd 4 1/7/13 3:13 PM
