Maintenance
10 --- 74
Unscrew the fitting (20) and carefully put the parts to one side; pull out the copper
pipe at item (15).
Unscrew the fittings (19) from the ends of the air pipe (16).
Withdraw the air pipe from the minimum pressure/check valve (25) and push carefully
to one side.
Remove the cover retaining screws (17) and carefully lift the cover (14).
The oil separator element cannot be cleaned.
Dispose of parts and materials contaminated with oil in accordance
with local environment protection regulations.
Take out the old oil separator element (23) together with the gaskets (21) and dispose
of according to environmental regulations.
Wipe all sealing faces with a cleaning rag.
Insert the new oil separator cartridge with gaskets and re---fix the cover.
Renew the dirt trap (15) strainer and O---ring.
Connect the air pipe to the minimum pressure/check valve.
Replace and tighten all fittings.
Start the machine and carry out a test run
Close all access doors; replace and secure all removable panels.
Open the user’s shut---off valve between the machine and the air main.
Switch on the power supply and reset the maintenance interval counter.
Allow the machine to idle for at least one minute. Then switch to LOAD.
Carry out a visual check for leaks.
