Full Digital Mechanical Sector Scanning Ultrasonic Diagnostic Instruments (Vet) User’s Manual V2.14
6.9.2 Open image
1. Freeze the image;
2. Continuously press key twice, a “Read” prompt appears on lower right corner of the screen;
3. Press direction keys to select the image code need to be read out, such as choose “003*”;
4. Press key, the image stored in frame “003*” is read out;
5. Press key to quit reading status and press key to return to real-time status.
Explanation: When reading images, it must choose the image code with mark “*”.
6.10 Delete the image
1. Freeze the image, press key to enter reading image status;
2. Press direction key to select the image code to be deleted, such as “002*”;
3. Press key, the image will be deleted, “*” will automatically disappear;
4. Repeat the 2-3 steps, delete other images;
5. Press key to return to real-time mode.
6.11 Text Input
Operation steps:
1. Freeze the image;
2. Press key, the cursor is located behind “EAR ID”;
3. Press key again, at the same time characters input menu will be shown at the bottom of the
screen:
Caps 0 1 2 3 4 A B C D E F G H I J K L M
Shift 5 6 7 8 9 N O P Q R S T U V W X Y Z
Press direction keys to move cursor to point to Caps, and then press key to achieve capital and
small letter conversion; If the cursor point to Shift, press key to achieve the conversion between
the letter and punctuation;
4. Press direction keys to choose “numbers” or “characters” and press key to confirm;
5. After inputting “EAR ID”, press key, the screen below shows “Pregnancy, Unpregnancy,
Uncertain” three kinds of results; at the same time the date and time of inspection automatically
shown behind the result;
6. Press direction keys to select the result, press key to confirm and exit;
7. Press key, the cursor is located behind EAR ID, press direction keys to move cursor to image
area and press key again to input according to Step 4;
8. If need modify the content, continuously press key twice to quit annotation status, press
direction keys to select “Clear”, at last press key to clear all noted marks and retype;
9. Press key to quit.
6.12 Obstetric list management
6.12.1 Save and view obstetric list
Storage to main unit
1. Freeze the desired image of B-mode; record the “EAR ID” and “Result” according to the text input
method;
2. Press key to confirm and exit;
3. Press direction keys to move cursor to “LIST”, press direction keys to enter obstetric list
