VII User Manual | Pedelec Groove 5
1 Quick start
› 1. Charge the battery completely before riding for
the rst time.
› 2. Open the round charging socket cover on the
back of the battery.
Now insert the plug of the charger into the battery
charging socket.
Charging the battery
› 3. Insert the mains plug for the charger into the
socket.
You must lly charge the battery before using it for
the rst time.
› 4. The battery is lly charged if all green LEDs on
the back of the battery light up when you press the
adjacent button.
Button on the battery
Pull the charger plug out of the battery socket.
Close the charging socket cover
You can also remove the battery om your Pedelec
and charge it somewhere else. For more informa-
tion, refer to ➠
Chapter 4 “Charging the battery”.
› 5. If you have charged the battery somewhere
other than on the Pedelec, place the battery back
into the holder in the pannier rack by reinserting it
om behind. Once you have inserted the battery,
turn the key clockwise and then remove it, other-
wise the battery will not lock into position.
› 6. Make sure that the battery is securely posi-
tioned and that the key is no longer in the lock.
› 7. Press the round switch on the side of the bat-
tery housing. The red LED inside it lights up.
› 8. Push the POWER button on the control panel on
the handlebar.
› 9. The display panel now displays the medium
power-assist mode SPORT. Press the Mode button
to select the level of assistance: ECO (low), SPORT
(medium) or POWER (high). Press this button once
to change the level of assistance by one level. Once
the POWER assist level has been activated, the as-
sistance jumps back to ECO the next time the but-
ton is pressed.
You can ride o just as you would if you were riding a
normal bike. The power assist starts aer roughly two
complete crank revolutions.
› 10. You can now ride o.
Charging socket
Switch, battery housing
