VII User Manual | Pedelec Groove 1515
Do not use other chargers. Only charge the battery us-
ing the charger provided, or a charger approved by us.
If a problem occurs, remove the battery om the Pe-
delec and place it briey in the charger. The charger
tests the battery and corrects any faults that may be
present.
If used incorrectly, the device may be damaged or
inict injuries.
› Before cleaning the charger, always pull the plug
out of the socket to avoid a short-circuit and/or
physical injury.
› Only use the charger in dry rooms.
› Only place the charger in an upright, secure and
stable position on a suitable surface.
› Do not cover the charger or place any objects on
it as otherwise it could overheat and catch re.
9 Removing the ont wheel
If you need to remove the ont wheel, to repair a punc-
ture for example, this can be done in the same way as
removing the ont wheel of a normal bike, excluding one
procedure.
› The rst thing you must do before releasing the
ont wheel is to open the connection to the ont
wheel motor.
› Undo the locking nut for the electrical connector
which is located on the back of the fork. Take the up-
per half of the connector in one hand and the lower
half in the other and pull the two halves apart.
1 Locking nut
2 Cable tie
1
2
The lower half of the connector and the power cable are
fastened to the fork with two cable ties.
› Slide the cable ties down and o the fork. You can
now remove the ont wheel. You can nd corre-
sponding instructions in the section of this User
Manual that deals with general bike technology. If
you take the ont wheel out of the fork, also pull
the cable and cable tie o the fork.
› To reinstall the ont wheel, slide the cable tie
with cable onto the fork leg before positioning the
wheel in the fork. Install the ont wheel as de-
scribed in the general section of this User Manual.
› Next, reattach the two halves of the connector and
screw the lock nut rmly back on. Slide the two ca-
ble ties back up the fork until they remain in place
of their own accord and cannot slip.
