Kane 100-1 - 10. Specification; Gas Measurement Specifications; Physical and Operating Specifications; Battery Charger Specifications

Page 17 English 18259
10. SPECIFICATION
Parameter Resolution Accuracy*1
Specified
Range
Over
Range
Gas Measurement
Carbon Monoxide
Carbon Dioxide
1 ppm
1 ppm
+/-5 ppm <100ppm
+/-5% > 100ppm
+/-10% >1000ppm
+/-20ppm <400ppm
+/-5% < 4000ppm
+/-10% >4000ppm
1000 ppm
200 to 4000 ppm
2000ppm
9999ppm
Dimensions
Weight
Handset
1kg / 2.2lb
200mm / 7.9” x 45mm / 1.8” x 90mm / 3.5”
Ambient Operating Range
+0°C to +45°C / 32-104°F
10% to 90% RH non- condensing
Battery Life
6 hours from full charge and with pump on
Battery Charger (standard
type trickle charger)
Input: 100 - 240 V ac 50 - 60 Hz
Output: 12V dc. @ 800 mA. Max.
*1
Using dry gases at STP with the instrument not subjected to sudden changes of temperature,
position or severe vibration
