2.4 Connecting NVMe Drives
The KanguruClone 4 NVMe supports NVMe SSDs that have an M.2 M-keyed connector. The
duplicator only supports drives that run on the PCIe protocol, so M.2 SATA drives are not supported.
To connect an NVMe solid state drive to the KangurClone 4 NVMe:
1. Make sure all Drive Locking Pins are positioned at the end of the duplicator.
2. Position the drive with the M-key notch aligned to the right side.
3. Insert the drive at about a 300 angle. You can identify the Source port position by the blue LED
indicator.
