4.4 ADJUSTING THE ANGLE OF THE KPT522
1. Loosen the Angle Locking Wheel on the mounting bracket, and adjust the
vertical and horizontal angle of the camera.
2. Tighten the Angle Locking Wheel to lock the position of the camera.
3M adhesive
Sticker
Angle Locking
Wheel
Mounting
Lock Wheel
(Fig .1) Window Mount
