4.5 INSTALLING THE REAR CAMERA
4.5.1 INSTALLATION GUIDE
1. Select a lat and centred location near the number plate lamp at the rear of
the vehicle to mount camera.
2. Attach tape to the bracket of the camera to hold
the camera in position while installing, and drill two
small holes, one for the irst screw, the second to
run the reverse camera cable through.
3. Use a screw driver to ix the irst screw, leaving the screw loose enough to
adjust the camera.
4. Insert the camera wire through the intended drilled
hole checking the installation position.
