Power switch
The power switch prevents unintentional operation of
the device.
High-pressure gun lock
The lock locks the lever of the high-pressure gun and
prevents the device from starting unintentionally.
Auto-stop function
If the lever of the high-pressure gun is released, the
pressure switch turns off the pump and the high-pres-
sure jet stops. The pump switches on again when the le-
ver is pressed.
Motor circuit breaker
The motor circuit breaker shuts off the device if power
consumption it too high.
Symbols on the device
Intended use
Use the high-pressure cleaner in private households
only.
The high-pressure cleaner is intended for cleaning ma-
chines, vehicles, buildings, tools, façades, terraces,
garden machines etc. using a high-pressure water jet.
Environmental protection
The packing materials can be recycled. Please
dispose of packaging in accordance with the en-
vironmental regulations.
Electrical and electronic devices contain valua-
ble, recyclable materials and often components
such as batteries, rechargeable batteries or oil,
which - if handled or disposed of incorrectly - can
pose a potential danger to human health and the envi-
ronment. However, these components are required for
the correct operation of the device. Devices marked by
this symbol are not allowed to be disposed of together
with the household rubbish.
Cleaning work producing in oily waste water, e.g.
washing engines, washing undercarriages etc.,
may only be performed at washing stations with an oil
separator.
Working with detergents may only be performed on
watertight surfaces with connection to the waste
water sewage system. Do not allow detergent to enter
waterways or the soil.
Extraction of water from public waterways is not
permitted in some countries.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.de/REACH
Accessories and spare parts
Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.
Scope of delivery
The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.
Device description
For the figures, please refer to the graphics page
Illustration A
1 Spray lance dirt grinder for stubborn soiling
2 Vario Power spray lance for common cleaning tasks
The working pressure can be continuously in-
creased from "SOFT" to "HARD". To adjust the
working pressure, release the trigger gun lever and
turn the spray lance to the desired position. Deter-
gent can be added to the water jet when the spray
lance is turned all the way in the SOFT direction.
3 High-pressure gun
4 Release button
5 High-pressure gun lock
6 High-pressure gun lever
7 Trigger "0/OFF" / "I/ON"
8 Storage for spray lances
9 Transport handle
10 Storage for high-pressure hose / mains connection
cable
11 Storage for high-pressure gun
12 Wheel
13 Type plate
14 Clamp for connecting / disconnecting the high-pres-
sure hose
15 High-pressure hose
16 *Garden hose (fabric reinforced, diameter at least
1/2 inch (13 mm), length at least 7.5 m, with com-
mercially available quick coupling)
17 Water connection coupling
18 **KÄRCHER suction hose for water supply from
open containers
19 Water connection with integrated sieve
20 Mains connection cable with mains plug
21 Screws
22 Detergent suction hose
* additionally required
** optionally available
Installation
For the illustrations, refer to the graphics page.
Fit the supplied loose parts onto the device before start-
ing up the device.
Have the included screws and the appropriate screw-
driver ready.
Do not aim the high-pressure jet may at per-
sons, animals, live electrical equipment or
the device itself.
Protect the device against frost.
The device may not be connected to the
public drinking water network.
