38
TECHNICAL SPECIFICATION
Elevation max 75°
Elevation 45°
Rotary axis
Mounting plate
Tightening range 20/50
Nut
Roof gland
137.5 including mounting plate
135.5
(807.3)
(790.3)
(700.4)
(443.3)
