39
TECHNICAL SPECIFICATION
Ignition signal 12…24 V
Search time for fi rst satellite (typ.) 10…120 s
Search time for further satellites (typ.) 2…30 s
Search time for LSM 2…15 s
(LSM = Last Satellite Memory)
Type CAP 710
Part no. 20310021
LNB
1 output switchable:
V/H (14/18 V)
low/high (0/22 kHz)
Supply voltage LNB V
vertical: 11.5-14
horizontal: 16-19
Input frequency GHz 10.70-12.75
Output frequency MHz 950-1950/1100-2150
Oscillator frequency (L.O.) GHz 9.75/10.60
System quality (G/T) 11.3/12.5 GHz dB/K 13.4/13.7
Power supply (vehicle battery) V 10.9-13.8
Power consumption from the 12 V vehicle
electrical system:
Inrush current
Satellite search
TV reception
Stand-by
A
Type 10, max. 12
typ. 3
typ. 1.2
typ. 0.024
Current consumption from the receiver mA typ. 160
Setting range:
Elevation
Azimuth
Skew
°
0-75
370
± 45
Weight of the turntable with parabolic
refl ector
kg 9.7
Packing unit/weight pc./kg 1/15.3
