2 – 3
OPERATION
ELECTRONIC MONITOR PANEL
(1) Engine Oil Pressure
Warninge Lamp
(2) Charge Warning Lamp
(3) Quick Grow Lamp
(4) Fuel Level Gauge
(5) Water Temperature Gauge
1. MONITOR LAMPS
c
Engine Oil Pressure Warning Lamp
When warning lamp comes on and the action alarm
sounds with the engine running, stop the engine.
This indicates insufficient oil pressure.
Check the engine oil level and have any necessary
repairs made before starting the engine.
d
Charge Warning Lamp
This indicates a malfunction in the electrical
charging system.
If the light comes on while the engine is running,
check the electrical system.
e
Quick GIow Lamp
This lamp indicates preheating status of the engine
in its starting period.
It lights when the start switch is turned ON and goes
out when a preheating st
age is over
.
Lighting time of this lamp becomes shorter when
the
engine is already warmed.
3
1
5
2
4
