2 – 23
OPERATION
STEERING
To make turns, control the travel levers.
Control the two travel levers as follows.
Pivot Left Turn
Move the right lever
c
forward to travel forward and
left, and move it rear to travel reverse and left,
pivoting on the left track.
Pivot Right Turn
Move the left lever
d
forward to travel forward and
right, and move it rear to travel reverse and right,
pivoting on the right track.
SPOT TURN
S
pot Lef
t T
urn
Move the left travel lever
d
rear and move the right
lever
c
forward at the same time. This allows a
quick left turn.
Spot Right Turn
Move the right travel lever
c
rear and move the left
lever
d
forward at the same time, allowing a quick
right turn.
