5.5 Conversion for contra-angle handpiece drill bit
Note
The handpiece must be converted to use contra-angle handpiece drill bits.
▶ Open the handpiece chuck.
▶ Insert the accompanying drill bit stop into the chuck.
▶ Press the contra-angle handpiece drill bit against the stop, close the
clamping ring and make sure that the bit is firmly seated.
▶ Use the accompanying hook to remove the bit stop.
Operation 30
