Operating Instructions | KBL Tower space 2000
11
The tanning device is by default set up to operate
on 3 phases but it can be changed over to 2-phase
operation. The wiring for 3-phase operation is shown
below:
The wiring for 2-phase operation is shown below.
• Re-wire the 3 cables according to the diagram.
• Make sure that you use the right cable for the
power supply.
4.4 Connecting an external audio
source
The cinch marked in the illustration is connected to
the external audio source where the line-out of the
sound player or the headphone/loudspeaker jack are
available for connection.
4.5 Level adjustment studio
music
The voice / audio system components are installed in
the back part of the tanning device. The potentiometer
which serves to adjust the external audio signal level
is accessible through a maintenance hatch on the left
hand side of the tanning device. To avoid overdrive,
select the level adjustment accordingly. The level
setting depends on the strength of the external signal
and should be carried out by a service engineer.
4.6 Operation using different
audio sources
The tanning device can be operated using the
following audio sources:
• An internal audio source
• Various external audio sources
• All available audio sources
The audio source can be changed via the control
panel.
INTERNAL MP3 PLAYER
When using the internal MP3 player, you can either
play the music tracks that are originally supplied on
the SD card, or you can record your own tracks to
the SD card.
