Operating Instructions | KBL Tower space 2000
41
DOOR
• Place a suction cup in the centre of the respective
pane and slowly pull the pane towards the front.
• Loosen the pane at one corner and go on down-
wards, then pull the pane off.
Caution
Place the door panel carefully on a pad-
ded surface.
There is one decorative tube beneath the door panel.
Turn the tube a quarter turn to the right and take it
out towards the front. Replace the tube, the colour
filter (if present) and the starter. Fasten door panel
again.
LATERAL PARTS
Dismantle the acrylic pane in the respective lateral
part as described in section “Cleaning and replacing
the acrylic panes”.
Remove the two front tubes in the left and right lat-
eral part (they are marked in the illustration below).
Underneath you will find the lighting equipment.
Replace the lighting tube and, if present, the colour
filter, with new parts.
Re-install the UV tubes and the pane.
