Operating instructions multicomp
Version 1.00 Page 21 of 29
EDEBDA0144 / 0511-1 GB
7.8 Error message menu
Selection of submenus with button
W
.
In the submenus of this window, the possible messages are displayed, as well as the display configuration.
The following error messages can be configured:
If a submenu is selected (using the button
W), the error message dialog can be changed by pressing the
buttons
U to start
entering values, V to change the settings and X to save them.
Message menu
next î D
Alarm submenu Possible actions
Off
Message
Alarm relay
Message and relay
Missing measurement voltage
9999
Missing stage power
9999
Facility too small
9999
THD (voltage harmonics) too high
9999
Switching cycle limit exceeded
9999
Missing current
9999
Light load operation
9999
a
Caution!
If there is a Stage monitoring error (cf. menu Extras (7.9), submenu
Monitoring stage power), no message is displayed, and only the
stages in the start menu window are marked with an X.
