Operating instructions multicomp
Page 28 of 29 Version 1.00
EDEBDA0144 / 0511-1 GB
11.9 Mechanical data
11.10 Standards and Miscellaneous
11.11 Overvoltage category
Flush-mounted
device
Housing measures 144 x 144 x 60 mm (H x W x D),
Mounting cutout 138 x 138 mm
Mode of protection Front IP51 (with optionally available front door max. IP54), terminals IP20
Weight approx. 650g
Environmental
conditions
Standards DIN EN 60721-3-3/A2: 1997-07; 3K5+3Z11; (IEC721-3-3; 3K5+3Z11)
Operating temperature - 5°C ….+55°C
Humidity 5% …....95%
Storage temperature -25°C ….+70°C
Electrical safety Standards DIN EN 61010-1/A2: Aug. 2002; (IEC1010-1/A2)
Protection class II, in accordance with DIN EN 61010-/A2: Aug. 2002
Overvoltage category CAT III: U
PH-PH
up to 400V
Mode of protection IP20 in accordance with DIN EN 40050 Part 9: 1993-05
Electromagnetic compatibility DIN EN 61000-6-3: 2005-6; (IEC 61000-6-3)
DIN EN 61000-6-2: 2005; (IEC 61000-6-2)
Password protection 4-digit Deleting and programming parameters on the device is not enabled if
password protection is active.
Measuring input for voltage Overvoltage category CAT III
Relay outputs Overvoltage category CAT II: Switching voltage up to 250V (AC)
Input control voltage Overvoltage category CAT III: 85 - 265V AC/DC
