5 Technical Data
5.1 Power supply
Power supply <10VA; 100 - 240V ±10% DC/50/60 Hz
5.2 Electrical Connection
Connection elements Plug-in terminals
Input control voltage Fuse max. 6 A
LAN connection 8P8C modular connector
BUS connection Connection
material
For proper operation,
use shielded twisted-pair cables
only; e.g. I-Y(St)Y2x2x0.8
BUS connection
multisys D2-ESET/MSMT-4
Pins for
BUS connection
via RS-485
Device
Terminal 90 ( )
Terminal 91 (A)
Terminal 92 (B)
BUS connection
multisys D2-BSET-4
6 pole modular cable,
RJ-12 connector: 6P6C
max. DC output power: 4 W
5.3 Mechanical data
DIN rail measuring device
Housing dimensions 90x36 x61mm (H x W x D),
Mounting type
Wall mounting on DIN rail 7.5 mm
deep, in accordance with
DIN EN 50022. Suitable for
distribution board mounting
Weight Approx. 120g
