GB - 25
CP-Parameter
25 Active current > switching level
26 Intermediate circuit voltage (CP.7) > switching level
27 Real value (CP.1) > switching level
28 Set value (CP.2) > switching level
31 Absolute set value at AN1 > switching level
32 Absolute set value at AN2 > switching level
34 Set value at AN1 > switching level
35 Set value at AN2 > switching level
40 Hardware current limit activated
41 modulation on
44 Inverter status > switching level
45 Power stage temperature > switching level
46 Motor temperature > switching level
47 Ramp output value > switching level
48 Apparent current (CP.4) > switching level
49 Forward running (not at nOP, LS, abnormal stopping or error)
50 Reverse running (not at nOP, LS, abnormal stopping or error)
63 Absolut ANOUT1 > switching level
64 Absolut ANOUT2 > switching level
65 ANOUT1 > switching level
66 ANOUT2 > switching level
70 Driving current active (safety relay)
73 Absolute active power > switching level
74 Active power > switching level
No listed values are only for application mode.
