GB - 26
CP-Parameter
CP.34 Source of rotation direction
The source rotation setting and the mode of evaluating the rotation setting is dened with
this parameter (Enter-Parameter). With CP.34 one does not modify the rotation source of
the xed frequencies (CP.19…21).
Value Direction of rotation
0/1 only application mode
2 Setting by way of terminal strip forward/reverse; negative set values are set to
zero (factory setting)
3 Setting by way of terminal strip forward/reverse; the sign of the set point values
have no effect on direction of rotation
4 Setting by way of terminal strip run/stop (X2A.14) and forward/reverse (X2A.15);
negative values are set to zero
5 Setting by way of terminal strip run/stop (X2A.14) and forward/reverse (X2A.15);
the sign of the set point values have no effect on direction of rotation
6 Set value dependent, positive value = clockwise rotation; negative value-counter-
clockwise rotation; Status "Low speed" (LS) if no terminal For or Rev is active
7 Set value dependent, positive value = clockwise rotation; negative value = counter
clockwise rotation clockwise rotation is indicated if set value is "0"
8/9 only application mode
CP.35 AN1 Set value selection
The setpoint input 1 (AN1) at the F5-GENERAL/COMPACT control can be driven by various
signal levels. In order to correctly evaluate the signal, this parameter must be adapted to
the signal source. At F5 Basic control board at housing type A or B the signal source may
not be re-adjusted.
Value Set value signal
0 0…±10 V DC / GENERAL/COMPACT Ri = 55 kΩ / BASIC Ri = 30 kΩ
1 0…±20 mA DC / Ri = 250 Ω
2 4…20 mA DC / Ri = 250 Ω
