63
COMBIVERT F3
ANTRIEBSTECHNIK
Das jeweils 1. Digit ergibt sich aus der Umwandlung eines 4-Bit-
Wortes in eine Hex-Zahl.
Das 4-Bit-Wort setzt sich wie folgt zusammen:
The first digit is a result of the conversion of one 4 bit word into a
hexadecimal number.
The 4 bit word is comprised as follows:
0 Kontakt arbeitet als Schließer.
Contact works as closing contact.
1 Kontakt arbeitet als Öffner.
Contact works as opening contact.
0 Eingang wird ständig abgefragt.
Constant input inquiry.
1 Eingang wird nur im Run-Mode abgefragt.
Input inquiry only in Run-Mode.
00 Es wird über DEC1-Rampe gestoppt (bn-02).
1)
Stopping is effected by DEC1 ramp (bn-02).
1)
01 Motor läuft frei aus.
1)
Motor decelerates uncontrolled.
1)
10 Es wird über DEC2-Rampe gestoppt (bn-04).
1)
Stopping is effected by DEC2 ramp (bn-04).
1)
11 Fehler blinkt in der Anzeige / Betrieb wird fortgesetzt.
2)
Fault blinks in the display / Operation is continued.
2)
= 7 Hex Klemme 5 und Fehler 1 sollen nun mit dieser
Kombination programmiert werden.
Terminal 5 and Fault 1 shall now be
programmed with this combination.
2
4
2
2
2
1
2
0
0111
Sn - 15 = 2 7
Klemme 5 Fehler 1
Terminal 5 Fault 1
1)
Primary Fault
- Immediate switching of fault relay.
- Reset possible only after DEC ramp.
- In case of several simultaneous faults the following priority
applies:
1. Uncontrolled deceleration
2. DEC2 ramp
3. DEC1 ramp
- By external fault Auto-Reset and Auto-Restart are not active.
2)
Secondary Fault
- Operation continues
- Fault relay does not switch
1)
Hauptfehler
- Das Störmelderelais schaltet sofort
- Reset ist erst nach DEC-Rampe möglich.
- Bei mehreren gleichzeitigen Fehlern gilt flgd. Priorität:
1. Freies Auslaufen
2. DEC2-Rampe
3. DEC1-Rampe
- Bei externem Fehler ist Auto-Reset/-Restart nicht aktiv
2)
Nebenfehler
- Betrieb wird fortgesetzt
- Störmelderelais schaltet nicht
