KEB COMBIVERT F4-S/1.2 User Manual

di - Parameter
61
ANTRIEBSTECHNIK
In each of these parameters, in which the respective function should be activated, the
respective decimal value is adjusted. If the function should be valid for several inputs,
then the sum of the decimal values is adjusted. For the input ST there are exceptions,
which is described in each parameter. The following assignments are valid.
Bit - No. Decimal Value Input
01ST
12RST
24 F
38R
416 I1
532 I2
This parameter adjusts, whether input signal 1 or 0 is active (inverted).
Input ST is always 1!
These parameters adjust the function of the programmable inputs (I1 - I2).
Parameter
Value
Input Function
0 no function
1 input used for set selection
2 reset for set selection
3 input activates DC - braking
4 no function
5 input activates LAD stop
6 input triggers external errors (E. EF)
7 no function
8 no function
9 input used for step speed switch over
(is only available with I1 and I2).
Specifies, whether the the input signal can directly be re-processed (condition
evaluated), or whether the internal state changes with every positive slope (at the
output of the logic selection!) of the input (input active).
Input ST is not input dependent!
In di.15 it can be selected for each input, whether the state of the control terminal or
the state of parameter di.16 is evaulated.
In di.16 the inputs can be set by the software. For this the corresponding inputs must
be selected in di.16.
Attention:
The input ST is an exception. In case the digital presetting of the control release is
adjusted (Bit 0 from di.15 = 1), then the signal must be preset by the terminal strip
and
by the parameter di.16 (Bit 0).
Bit Coded
Parameters
di. 2, di.14 - di.18
Input Logic
(di. 2)
Input Functions
(di. 3, di. 4)
Input Trigger
(di.14)
Select Signal
Source (di.15)
Digital Input
Setting (di.16)
