CP.31 Relay output 1 / function (terminals X2A.24...26)
CP.32 Relay output 2 / function (terminals X2A.27...29)
Value Function
0 No function (generally off)
1 Generally on
2 Run signal; also by DC-braking
3 Ready signal (no error)
4 Fault relay
5 Fault relay (without auto-reset)
6 Warning or error message at abnormal stopping
7 Overload pre-warning
8 Overtemperature alert signal power stage
9 External Overtemperature alert signal motor
11 Overtemperature alert signal interior OHI
12 Cable breakage 4...20 mA on analog input 1
14 max. constant current (Stall, CP.25) exceeded
15 max. ramp current (LA-Stop, CP.24) exceeded
16 DC-braking active
20 Actual value = set value (CP.3 = Fcon, rcon; not at noP, LS, error, SSF)
21 Accelerate (CP.3 = FAcc, rAcc, LAS)
22 Decelerate (CP.3 = FdEc, rdEc, LdS)
23 Real direction of rotation = set direction of rotation
24 Utilization (CP.6) > switching level
25 Active current > switching level
26 Intermediate circuit voltage (CP.7) > switching level
27 Real value (CP.1) > switching level
28 Set value (CP.2) > switching level
31 Absolute set value at AN1 > switching level
32 Absolute set value at AN2 > switching level
34 Set value at AN1 > switching level
35 Set value at AN2 > switching level
40 Hardware current limit activated
41 modulation on
44 Inverter status > switching level
45 Power stage temperature > switching level
46 Motor temperature > switching level
47 Ramp output value > switching level
48 Apparent current (CP.4) > switching level
49 Forward running (not at nOP, LS, abnormal stopping or error)
50 Reverse running (not at nOP, LS, abnormal stopping or error)
63 Absolut ANOUT1 > switching level
64 Absolut ANOUT2 > switching level
65 ANOUT1 > switching level
66 ANOUT2 > switching level
70 Driving current active (safety relay)
73 Absolute active power > switching level
74 Active power > switching level
The switching level of CP.31 is pre-set to 100,00.
The switching level of CP.32 is adjusted by CP.33!
No listed values are only for application mode.
