Appendix
22
©
2020 KEB America, Inc.
6 Appendix
6.1 Appendix 1: Recommended Distribution Block TB
Used for the parallel connection of the brake resistor and the Brake Transistor
Monitor.
Two single-phase distribution blocks are required.
nVent ERIFLEX UD-80A 569010
https://www.erico.com/part.asp?part=UD-80A
KEB Material Number 0090503-5001
6.2 Appendix 2: Recommended DC Contactor
Used to disconnect the BR- connection to the brake resistor.
GIGAVAC® GV250 Series Contactor
https://www.gigavac.com/sites/default/files/catalog/spec_sheet/gv250.pdf
KEB Material Number 0090215-2601
6.3 Revision History
Chapter Change Date
All Initial Publication 6/11/2020
