4.2 Outputs
Theshort-circuitproof,digitaloutputsarespeciedinaccordancewithIEC61131-2.Theoutputrated
current is 100 mA.
4.2.1 Output STO
Output (status-STO) provides a 24V signal if the modulation is possible.
4.2.2 Output SBC
Output (status SBC) provides a 24V signal if the brakes are released (see „6.3 Functional descrip-
tion SBC“).
4.2.3 Brake output
The position of the terminals and specication of the brake output is described in the respective
COMBIVERT manual. The free-wheeling path to control the brake is integrated in the COMBIVERT.
4.3 Status LEDs
The arrangement of the LEDs is stored in the corresponding COMBIVERT manual.
4.3.1 Status-LED safety module
The LED indicate the state of the safety module.
LED Status
Off No voltage supply of the safety module
Green Safety module in operation
Red Safety module in error
Table 10: Status-LED safety module
Further status messages see chapter „6 Functional Descriptions“.
