Annex
• In order to comply with CSA C22.2 No. 14-2010 (cUL) following external Input Chokes
need to be installed: See table 1 below!
Table 1: Mains input chokes for CSA applications:
Cat. No. Housing Input Voltage [V] Reactor Cat. No. FLA Inductance [mH]
13G6 B, C 480 / 3ph 13DRB08–1851 3 x 16A 1.83
14G6 C 480 / 3ph 14DRB08–1451 3 x 20A 1.47
15G6 C 480 / 3ph 15DRB08–9841 3 x 30A 0.98
Branch Circuit Protection for G6 - C Drive series
I) Fuses:
Cat. No. Housing Input Voltage
[V]
Class CC, J or RK5
UL248 Fuse rating 600V [A]
13G6 B, C 480 / 3ph 20
14G6 C 480 / 3ph 25
15G6 C 480 / 3ph 40
The voltage rating of the external fuses shall be at least equal to the input voltage of the dri-
ves.
II) Listed (DIVQ, DIVQ7/CSA Certied ) Circuit Breakers, Type, manufacturer and electrical
ratings as specied below:
Cat. No. Housing Type Manufacturer Ratings
13G6 B or C 5SJ4 320-8HG42
S203UP-K 20
FAZ D20/3-NA
1489 A3D 200
Siemens
ABB
Eaton
Allen Bradley
480Y/277V, 20A
14G6 C 5SJ4 325-8HG42
S203UP-K 25
FAZ D25/3-NA
1489 A3D 250
Siemens
ABB
Eaton
Allen Bradley
480Y/277V, 25A
15G6 C N/A N/A N/A
III) Listed (NKHJ, NKHJ7/CSA Certied) Type E Self Protected Manual Motor Controllers,
Type and manufacturer and electrical ratings as specied below:
Cat.
No.
Housing Self Protected Ma-
nual Motor Cont-
roller,
Type
Manufac-
turer
Self Protected
Manual Motor
Controller,
Ratings
Dial setting
[A]
13G6 B, C PKZM0(1) 25-E Eaton 480Y/277V, 15.0 Hp 25
14G6 C PKZM0(1) 25-E Eaton 480Y/277V, 15.0 Hp 25
15G6 C PKZM0(1) 32-E Eaton 480Y/277V, 20.0 Hp 32
