KEB G6 - Part Code

GB - 7
Preface
1.6 Part Code
xx G6 x x x - x x x x
Cooling (not valid at customer/special version)
0 Air-cooling (housing C, D, E); air-cooling/at rear (housing A, B)
1 Flat rear
Control/keyboard/display (not valid at customer/special version)
0 Open-loop without keyboard/display A like 0 on ASCL hardware
1 Open-loop with keyboard/display B like 1 on ASCL hardware
2 SCL without keyboard/display
3 SCL with keyboard/display
4 ASCL without keyboard/display
5 ASCL with keyboard/display
Switching frequency; short time current limit; overcurrent cut-off
(not valid at customer/special version)
0 2 kHz 125 % 150 % 1 4 kHz 125 % 150 %
2 8 kHz 125 % 150 % 3 16 kHz 125 % 150 %
4 2 kHz 150 % 180 % 5 4 kHz 150 % 180 %
6 8 kHz 150 % 180 % 7 16 kHz 150 % 180 %
8 2 kHz 180 % 216 % 9 4 kHz 180 % 216 %
A 8 kHz 180 % 216 % B 2 kHz 180 % 216 %
Voltage, connection
0 1-phase 230 V AC/DC 3 3-phase 400 V AC/DC
1 3-phase 230 V AC/DC 5 400 V DC
2 1/3-phase 230 V AC/DC 6 1-phase 230 V AC
A-Z Customer-/special version (rmware and download)
Housing type A, B, C, D, E
Variants
0
without lter, without braking transis-
tor,
without safety function STO
A
like 0 with
STO
H
like A with
f=0Hz
1
without lter, with braking transistor,
without safety function STO
B
like 1 with
STO
i
like B with
f=0Hz
2
internal lter; without braking tran-
sistor, without safety function STO
C
like 2 with
STO
K
like C with
f=0Hz
3
internal lter, with braking transistor,
without safety function STO
D
like 3 with
STO
L
like D with
f=0Hz
Control type
C Analog/digital (standard)
D CAN
E IO-link
F EtherCAT
G Pronet
G6 unit type
Inverter size
