3.1 Assembly 3.1
Adjusting the Legs
NOTE: When lifting the main body from the box do not lift using the black handles on
the cutters.
Remove the Main body from the box and lay it on the floor, remove the packaging from
the bottom end.
1. Slacken the bottom two screws on each leg using the 5mm Hexagon wrench and
extend the telescopic parts to the desired length. (These can be re-adjusted later
before fixing the machine to the wall). Tighten screws firmly to clamp in position.
2. Swing both legs outwards as far as they will go.
The first stages of assembly are carried out with the machine laying on the floor.
