Page #28 background image
28
Remove starting driven ratchet wheel by removing the nuts.
Rmove fan⑤ and V-belt⑥.
Disassemble the movable drive
face⑦.
Remove electric gear press board, electric
gear And super clutch
Remove starter motor

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KEEWAY Matrix and is the answer not in the manual?

KEEWAY Matrix Specifications

General IconGeneral
Fuel SystemCarburetor
Front SuspensionTelescopic fork
Front BrakeDisc
Rear BrakeDrum
Front Tire120/70-12
Rear Tire130/70-12
Width700 mm
Cooling SystemAir cooled
TransmissionAutomatic
