POWERED SUBWOOFER
10
CASING LED ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
1 7011-9360-0 UL1007 AWG#26 RAINBOW CN301
1 8912-0003-0 RF RECEIVER MODULE DUAL RF101
6 4152-6890-0 RUBBER PAD 2617-19-0 W/DOUBLE RF101
1 7010-0060-0 CN ASSY UL2547 #26 L=210 3P M/F RF101
1 1681-1000-A UL1007 AWG#20 BLACK L=620MM RF101
CASING PRE AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
4 2607-3009-0550 SPRING WASHER M3X0.9X5.5 PRE PCB
4 2904-3006-3000 SCREW M3X6 BINDING (BLK) PRE PCB
2 4135-0901-0 PCB BRACKET FC3T0C PRE PCB
CASING POWER AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
4 2600-3005-0800 METAL WASHER M3X0.5X8MM PCB
4 2600-3005-0800 METAL WASHER M3X0.5X8MM Q209 TO Q212
4 2607-3009-0550 SPRING WASHER M3X0.9X5.5 H.S BRACKET
4 2607-3009-0550 SPRING WASHER M3X0.9X5.5 HEATSINK
4 2607-3009-0550 SPRING WASHER M3X0.9X5.5 PWRM PCB
4 2607-3009-0550 SPRING WASHER M3X0.9X5.5 Q209 TO Q212
4 2900-3010-3000 SCREW PH M3X 10 MM BZ CR HEATSINK
4 2904-3006-3000 SCREW M3X6 BINDING (BLK) PRE PCB
4 2954-3010-3000 B-TITE 3X10MM (BLK.ZN) H.S BRACKET
4 2954-3014-3000 B-TITE 3X14MM(BLK.ZN) Q209 TO Q212
4 3100-3171-0 MICA SHEET A (24X20) Q209 TO Q212
4 4133-9580-0 BRASS TUBE 2751-10-0 HEATSINK
2 4135-0911-0 HEATSINK BRACKET FC3T0C HEATSINK
2 4860-5050-5 TR 2SC5200 T0-3P (L) TOSHIBA Q210 Q211
2 4860-5060-5 TR 2SA1943 T0-3P (L) TOSHIBA Q209 Q212
1 5200-3570-0 SW CB-SL1412 AM1BCEI AC SW2
1 5400-3401-0 HEATSINK FC3T0C Q209 TO Q212
PARTS LIST
To Next Page
