POWERED SUBWOOFER
PARTS LIST
POWER AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
4 150F-101K-5-IEA CC 50V 100pF 10% RL 5X3 C204,222,224,226
6 150F-104M-N-FD CC 50V 0.1µF 20% RLF C205, 207, 227, 252, 503,
504
1 150F-470K-5-IEA CC 50V 47pF 10% RL 5X3 C225
2 150F-471K-5-IEA CC 50V 470pF 10% RL 5x3 C202,217
2 150F-681J-5-OI CC 50V 680pF 5% RL 8X5 C235,236
1 153H-102K-5-INA CM 100V 0.001µF 10% RL C223
2 153H-104K-5-QUA CM 100V 0.1µF 10% RL C209,211
2 153H-224K-5-VYA CM 100V 0.22µF 10% RL C219,229
1 153I-154J-9-NL CM 63V 0.15µF 5% RB 7.5x C201
2 157D-107M-5-KW CE 16V 100µF 20% RL 6x12 C216,250
2 157D-227M-5-KW CE 16V 220µF 20% RL 6x12 C206,208
4 157D-476M-5-IU CE 16V 47µF 20% RL 5x11 C251,253,505,506
2 157F-476M-5-OWK CE 50V 47µF 20% RL 8x12 C501,502
2 157E-106M-5-IU CE 25V 10µF 20% RL 5x11 C220,232
2 157F-105M-5-IU CE 50V 1µF 20% RL 5x11 C218,230
2 157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11 C228,248
1 157F-474M-5-IU CE 50V 0.47µF 20% RL C233
2 157I-107M-5-SX CE 63V 100µF 20% RL C221,234
1 157Q-476M-5-LUA CE 35V 47µF 20% RL 6.5X11 C231
1 1806-2374-0 TT-9974 TOROIDAL CHOKE T L201
1 1806-2393-0 TT-9904 LE 1012A 1X12TX6 L202
1 2101-1380-0 HEADER 4P P=5MM VERTICAL CN201
1 2101-9120-0 JM24182-2P WAFER CN206
1 2101-9130-0 JM24182-4P WAFER CN501
1 3130-2020-2 IC 7805 REG 5V U205
1 3130-3550-0 IC TA7317P U206
1 3130-4080-0 IC TL072CP DUAL FET OP U204
1 3130-9150-0 IC LM3080N OTA NATIONAL U203
2 3131-7220-0 IC TL062 LOW POWER JFET U201,202
1 4132-1551-0 TERMINAL OUT PUT GND
2 4132-1551-0 TERMINAL OUT PUT SPK+,SPK-
1 4500-0890-0 RELAY 12VDC,250VAC,10A RLY202
1 4500-8090-0 RELAY RUDH-SH-124D "GOOD RLY201
1 4718-100J-C-X RMF 1W 10R 5% ATS METAL R249
4 474B-0R1J-1 RWR 5W 0.1 5% AL R236,238,241,245
1 4756-2036-3-15 SVR B20K H3 VZ067TL7B TP201
1 4860-1260-5 TR 2N3906 SAMSUNG RL Q201
1 4860-2280-5 TR TIP42C SGS Q208
