11
POWERED SUBWOOFER
CASING SMPS ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
1 1403-6680-0 SWITCH POWER TOP COVER TOP COVER
1 1403-6690-0 SWITCH POWER BOTTOM BOTTOM COVER
1 1806-2375-0 TT-9975 EARTH TOROIDAL C L7
1 1806-3556-0 CHOKE TRANSFORMER EI-41 L8
12113-9535-0 HALO BUSHING 0813C BOTTOM COVER
4 2600-3005-0803 METAL WASHER M3X0.5X8MM FAN1
4 2600-3005-0803 METAL WASHER M3X0.5X8MM PCB
2 2600-3005-0803 METAL WASHER M3X0.5X8MM TOP COVER
1 2606-4008-0853 INT TOOTH WASHER M4X0.8X L7
1 2606-4008-0853 INT TOOTH WASHER M4X0.8X RING T'NAL
4 2607-3009-0553 SPRING WASHER M3X0.9X5.5 FAN1
2 2607-3009-0553 SPRING WASHER M3X0.9X5.5 IEC1
6 2607-3009-0553 SPRING WASHER M3X0.9X5.5 PCB,L8
2 2607-3009-0553 SPRING WASHER M3X0.9X5.5 TOP COVER
1 2607-4010-0704 SPRING WASHER M4X1X7MM N L7
1 2607-4010-0704 SPRING WASHER M4X1X7MM N RING T'NAL
2 2640-3022-0544 M3 NUT NI IEC1
2 2640-3022-0544 M3 NUT NI L8
1 2640-4030-0704 NUT HEX M4 CN3
1 2640-4030-0704 NUT HEX M4 L7
4 2900-3008-3000 SCREW M3x8 PM BZ PCB
2 2900-3008-3000 SCREW M3x8 PM BZ SW2
2 2900-3008-3000 SCREW M3x8 PM BZ TOP COVER
4 2950-3008-0020 SCREW B-TITE PH M3X 8 MM D8-D11
4 2950-3008-0020 SCREW B-TITE PH M3X 8 MM Q1-Q4
6 2900-3010-3000 SCREW PH M3X 10 MM BZ CR FAN,L8
2 2900-3010-3000 SCREW PH M3X 10 MM BZ CR IEC1
4 2944-3008-3000 S-TITE 3X8 (BLK) TOP COVER
4 3100-8040-0 MICA T-400 8302 18X12.7M D8-D11
4 3100-8050-0 MICA T-400 T03P 25X20M T Q1-Q4
1 4135-1701-0 TERMINAL RING COPPER TIN CN2 CN3
1 4153-3331-0 EVA GASKET 5*500 TOP COVER
1 4153-3800-1 POWER INLET SOCKET IEC1
2 5120-9001-0 CERAMIC 5X20MM FUSE 250V F1
1 5200-3570-0-00 SW SY-113C12N AC SELECTO SW2
1 5200-9123-0 ROCKER SW 1P1T M372-499- SW1
1 6360-0011-0 PLASTIC CABLE TIE 97MM CN1
8 6360-0011-0 PLASTIC CABLE TIE 97MM CN2 CN3
1 6360-0011-0 PLASTIC CABLE TIE 97MM SW2
PARTS LIST
