KEF PSW 3000 - Parts List; Led Assembly; Pre Amplifier Assembly

POWERED SUBWOOFER
2
PARTS LIST
LED ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
1 1681-1000-A UL1007 AWG#20 BLACK L=310MM RF101
1 3700-4536-RG L-115W EGW/209EGW RED/GR LED301
1 3700-9528-0 LED DISP LR2x5-10B-YYB LED302
2 4860-8710-5 TR 9012H Q307,310
8 4860-8720-5 TR 9013H SAMSUNG Q301, 302, 303, 304, 305,
306, 308, 309
1 157C-107M-5-IU CE 10V 100µF 20% RL 5x11 C301
5 4701-101J-2 RCF 1/8W 100R 5% AT R301,302,303,304,305
1 4701-102J-2 RCF 1/8W 1K 5% AT R320
7 4701-103J-2 RCF 1/8W 10K 5% AT R311, 312, 313, 314, 315,
321, 322
2 4701-203J-2 RCF 1/8W 20K 5% AT R317,318
5 4701-331J-2 RCF 1/8W 330R 5% AT R306,307,308,309,310
1 4701-331J-C RCF 1/8W 330R 5% ATS R121
2 4701-472J-2 RCF 1/8W 4.7K 5% AT R316,319
10 4840-8060-2 DIODE 1N4148 NS D301, 302, 303, 304, 305,
306, 307, 308, 309, 310
1 1725-546A-0001 LED PCB FC3T0C 94HB
PRE AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
10 150D-104M-P-AC CC 16V 0.1µF 20% C120, 121, 122, 123, 124,
125, 126, 127, 128, 129
1 150F-101K-5-IEA CC 50V 100pF 10% RL 5X3 C14
4 150F-104M-N-FD CC 50V 0.1µF 20% RLF C19,30,109,110
5 150F-224M-N-II CC 50V 0.22µF 20% RLF MO C20,21,22,23,29,
8 150F-334M-N-JJA CC 50V 0.33µF 20% RLF MO C5, 10, 101, 102, 103,
104, 105, 106
1 153H-123K-5-KUA CM 100V 0.012µF 10% RL C28
1 153H-273J-5-MQA CM 100V 0.027µF 5% RL 7X C25
1 153H-393K-5-MRA CM 100V 0.039µF 10% RL C24
1 153H-683K-5-PSA CM 100V 0.068µF 10% RL C26
1 153H-822J-5-WQ CM 100V 0.0082µF 5% RL C27
4 153H-823K-5-QSA CM 100V 0.082µF 10% RL C2,4,8,9
1 157C-108M-5-O5 10V 8*15.5 1000µF+-20% A C157
1 157D-107M-5-KW CE 16V 100µF 20% RL 6x12 C17
1 157D-227M-5-KW CE 16V 220µF 20% RL 6x12 C111
1 157D-476M-5-IU CE 16V 47µF 20% RL 5x11 C18
