3
POWERED SUBWOOFER
PARTS LIST
PRE AMP ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
1 157D-477M-5-OVK CE 16V 470µF 20% RL C16
1 157E-106M-5-IU CE 25V 10µF 20% RL 5x11 C15
13 157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11 C1, 3, 7, 11, 13, 35, 150,
151,152,153,154,155,156
2 15CG-470J-7-IJ CTC 0/30 47pF 5% RM C107,108
2 1801-220K-M COIL 22µH 10% AL BL7 L101,102
2 1808-0670-0 FERRITE BEAD 26430000101 FB102,103
1 1808-9080-0 FERR BEAD 43120203106 1- FB101
1 2101-1357-0 WAFER JM2411-8 8PIN CN7
1 2101-1781-0 20 WAY IC SOCKET-DUAL IN U104
1 2101-9320-0 WAFER JM24182-11P CN102
1 2101-9790-0 4RCA JACK HSP-204V-03 GP RCA1
1 2703-0190-0 CR RESONATOR XTAL101
10 3131-6140-0 IC BA4560 ROHM U1,2,3,4,5,6,7,8,101,102
1 3131-7730-0 MCU AT89C4051-24PI ATMEL U104
1 3131-7740-0 EEPROM AT24C02-10PI U103
1 4132-1551-0 TERMINAL OUT PUT GND
2 4152-6890-0 RUBBER PAD 2617-19-0 W/B RF101
1 4701-100J-2 RCF 1/8W 10R 5% AT R129
2 4755-4746-2 SVR B470K 6MM TYPE VERTICAL TY TP104,105
3 4756-2026-3-05 SVR B2K H3 NVZ6TL1 HDK TP101,102,103
1 4859-014C-5 TR 9014C HFE 200-600 Q101
3 4860-8710-5 TR 9012H Q3,4,7
5 4860-8720-5 TR 9013H SAMSUNG Q1,2,5,6,16
7 4860-8770-0 TR FET J112 Q8,9,10,11,12,13,14
1 5200-3281-0-06 SW COMAX SW102
1 5200-4801-0 SW TACT X2 KPT-2105B SW101
1 7010-2221-0 3 PIN SHIELD WIRE ASSY CN1
1 7010-2222-0 3 PIN FLAT CABLE ASSY CN2
2 7011-3240-0 2254 1533 #26 2X2PIN BRN CN5,101
2 7011-4570-0 AMP108U AWG26 180MM BRWN CN4,6
2 8910-0042-0 CE 50V 300µF C6,12
1 8912-0003-0 RF RECEIVER MODULE DUAL RF101
1 4701-101J-2 RCF 1/8W 100R 5% AT R136
4 4701-102J-2 RCF 1/8W 1K 5% AT R10,22,37,40
2 4701-472J-2 RCF 1/8W 4.7K 5% AT R35,38
10 4701-103J-2 RCF 1/8W 10K 5% AT R5, 8, 18, 24, 25, 28, 36,
130, 132
To Next Page
