7
POWERED SUBWOOFER
POWER AMP ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
2 2954-2606-0000 SCREW BT 2.6X6 U501,502
2 2954-3008-3000 T3X8MM SELF TAPPING U501,502
1 3130-2520-2 IC 7812H 12V REG, T0220F U502
1 3130-3800-0 IC UPC79M12HF REGULATOR U501,502
2 5400-9130-0 HEAT SINK FOR 7805 2438- U501,502
SMPS ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
8 150F-104M-N-FD CC 50V 0.1µF 20% RLF C16, 17, 18, 19, 20, 22,
28, 32, 33, 34
1 150N-101K-5-MHA CC 1KV 100pF 10% RL C7
2 150N-471K-5-MHA CC 1KV 470pF 10% RL C9,10
2 150R-332M-5-1OA CC 250V 3300pF 20% RL DE1 C3,4
1 153H-102K-5-INA CM 100V 0.001µF 10% RL C23
2 153H-103K-5-KNA CM 100V 0.01µF 10% RL C25,27
1 153H-222K-5-INA CM 100V 0.0022µF 10% C26
1 153H-472K-5-JNA CM 100V 0.0047µF 10% RL C24
2 153Z-334M-5-YUM CM 275V 0.33µF 20% RL C1,2
1 157F-107M-5-OW CE 50V 100µF 20% RL 8x12 C30
1 157F-107M-5-OWK CE 50V 100µF 20% RL 8x12 C31
1 157F-225M-5-IUK CE 50V 2.2µF 20% RL 5x11 C29
2 157Q-477M-5-S9T CE 35V 470µF 20% 10X20 C8,13
2 157I-108M-5-5$K CE 63V 1000µF 20% RL 16X C11,12
2 157R-567M-5-#$T CE 250V 560µF 20% RL 105 C5,6
1 1681-1000-A UL1007 AGW#20 BLACK GND
1 1806-2372-0 TT-9972 GATE DRIVER TRAN T1
2 1806-2373-0 TT-9973 DIFFERENTIAL MOD L1,2
1 1806-2380-0 CURRENT TRANSFORMER T4
1 1806-2437-0 TT-01001 EE-42 POWER T3
1 1806-2442-0 CHOKE O/P T131-26 L5
1 1806-2443-0 COMMON MODE EE-35 L3
1 1806-2444-0 X-TRANSFORMER EI-28 T2
8 1808-0670-0 FERRITE BEAD 26430000101 FB5,6,7,8,9,10,11,12
1 1808-9030-0 ARRESTER 230V DC 5KA M2P G1
6 1808-9080-0 FERR BEAD 43120203106 1- FB1 TO FB4,FB13,14
1 2101-1343-0 WAFER 2219S-03-E2 P=7.92 CN1
1 3131-5550-0 IC KA3842B SAMSUNG U3
