9
POWERED SUBWOOFER
PACKING ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
1 1497-1932-0 POLYBAG 04x5x9" w/PE-LD REMOTE
1 2150-7001-0 NAME PLATE RF REMOTE REMOTE
2 4060-0530-0 GREENCELL 3A SIZE GP24G2 PACKING
4 4153-7941-0 K100081B BLANKING PIN BK SPK-
4 4153-7951-0 K100081J BLANKINGPIN RED SPK+
1 8912-0002-1 RF REMOTE DUAL CHANNAL PACKING
POWER CORD ASSEBLY
QTY PART NO DESCRIPTION LOCATION
1 7011-6220-0 H05VV-F 0.75MM/3C 2M BLK *EU
1 7011-5030-0 TC1490GP 3 CORE CORD 1/P *UK
1 7011-6210-0 SJT #18 /3C 2M BLK POWER CORD *US
1 2101-9140-0 WAFER JM24182-3P RF101
CASING ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
1 1403-6680-0 SWITCH POWER TOP COVER TOP COVER
1 1403-6690-0 SWITCH POWER BOTTOM BOTTOM
1 1403-6700-0 REAR PANEL FC3T0C HEATSINK
4 2103-7001-0 BINDING POST RED SPK IN+
4 2103-7101-0 BINDING POST BLK SPK IN-
8 2600-5008-1000 METAL WASHER M5X0.8X10MM SPK IN+
2 2606-3005-0643 INT TEETH WASHER M3X0.5X6.4MM REAR PANEL
8 2904-3006-3000 SCREW M3X6 BINDING (BLK) REAR PANEL
6 2944-3008-3000 S-TITE 3X8 (BLK) REAR PANEL
1 2954-3008-3000 T3X8MM SELF TAPPING RCA1
1 3100-5951-0 NET DUST FILTER FC3T0C REAR PANEL
1 4153-1250-0 2209 SW COVER 1-41-112 SW1
1 7010-2237-0 HOUSING ASSY JP2411-8P FOR SPK/IN
CASING LED ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
1 153H-104K-5-QUA CM 100V 0.1µF 10% RL C158
1 1808-0170-0 CLAMP CORE FOR EMI/RFI FB104
1 3100-6051-0 LED HOLD
1 6360-1322-0 PLASTIC CABLE TIE 200MM FB104
PARTS LIST
