Keith McMillen Instruments K-Board User Manual

3. Plug in your K-Board and open SysEx Librarian.
4. Click “Add...” in the lower-left corner of the screen. When the browser window opens,
navigate to the firmware file (generally named to the effect of “K-Board.syx”) then click
“Open”.
5. Select “K-Board” from the drop down menu labeled “Destination”.
6. Select the firmware file in SysEx Librarian’s main window — it should highlight blue.
7. Click the “Play” button in the top-left corner of SysEx Librarian to begin the firmware
installation. A progress bar will appear indicating how far along the update process is.
The K-Board will look non-responsive while the update is taking place — this is okay and
to be expected.
8. Once done, start using the K-Board as usual.
Windows
1. If you have not already, download and install SysEx Box from http://miostools.
midibox.org/
2. Download or locate the firmware file you would like to install. Zips of the current version
and past versions can be downloaded here: http://files.keithmcmillen.com/
downloads/kboard/sysex_files
3. Make sure all audio/MIDI applications are closed.
4. Plug in your K-Board and open SysEx Box.
5. Select “K-Board” in the “MIDI IN Port” and “MIDI OUT Port” drop-down menus.
“K-Board” may show up as “USB Audio Device” on Windows XP.
6. Click “Open Sysex File”. When the browser window opens, navigate to the firmware file
you want to send to the K-Board, then click “Open”.
7. Click the “Send Sysex” button. The firmware update should begin. The K-Board will look
non-responsive while the update is taking place — this is okay and to be expected.
8. Once done, start using the K-Board as usual.
FAQ | 24
