Keithley 2001 Quick Reference Guide

30
GPIB
ADDRESSABLE
TALK-ONLY
FEED
AFTER-CALC
BEFORE-CALC
NONE
INTERFACE
IEEE-488
CENTRONICS
INTERVAL
FORMFEED
CONTROL
SET-PAGE-SETUP
ELEMENTS
STATUS
GPIB/Printer Setup menu:
Check/change IEEE-488 bus
address (0-30).
GPIB/Printer Talk-only mode
menu:
GPIB Output Feed menu:
Specify reading after math
operation.
Specify reading before math
operation.
Specify no readings.
Select printer interface.
Specify IEEE-488 printer.
Specify Centronics parallel
printer.
Specify printing interval (every
reading to 1 out of 9999).
Formfeeds menu:
Enable/disable page breaks.
Set number line between
form feeds (1-255).
Select GPIB data elements (read-
ing, units, reading number,
channel number, timestamp,
status).
Display IEEE-488 bus status byte.
CALIBRATION
COMPREHENSIVE
AC-ONLY-CAL
CALIBRATION-DATES
Calibration menu:
Perform DC and AC calibration.
Perform AC calibration only
(open-circuit).
Check/change calibration date.
TEST
BUILT-IN-TEST
AUTOMATIC
MANUAL
DIAGNOSTICS
FRONT-PANEL-TESTS
KEYS
DISPLAY-PATTERNS
Self-test menu:
Test analog and digital boards.
Run all tests automatically.
Select tests to run.
Factory diagnostic tests.
Test display board.
Verify operation of front panel
keys.
Verify operation of display.
Table 17. Main menu structure (cont.)
Menu item Description

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
