Keithley 2001 Quick Reference Guide

37
Triggers:
Arm layer:
Source
Triglink input
Triglink output
Count
Control
Scan layer:
Source
Triglink input
Triglink output
Delay
Count
Control
Measure layer:
Source
Triglink mode
Triglink input
Triglink output
Timer
Delay
Count
Control
Armed
Immediate
Line 2
Line 1
1
Acceptor
Immediate
Line 2
Line 1
0
Infinite
Acceptor
Immediate
Asynchronous
Line 2
Line 1
0.1sec
0
Infinite
Acceptor
Idled
Immediate
Line 2
Line 1
1
Acceptor
Immediate
Line 2
Line 1
0
1
Acceptor
Immediate
Asynchronous
Line 2
Line 1
0.1sec
0
1
Acceptor
Table 18. Factory default conditions (cont.)
Function or operation Bench default GPIB default

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
