Keithley 2290-5 - Store and Recall

Model 2290
-5 5 kV Power Supply User's Manual Section 3:
Basic operations
2290-5-900-01 Rev. A/December 2013 3-3
Store and recall
STO (store) and RCL (recall) allow up to nine complete instrument setups to be saved in nonvolatile
memory and later recalled.
To store a setup:
1. Program the various instrument operating modes to be stored.
2. Press the STO button.
3. Press a number (1 to 9) to select the desired storage location.
4. Press the ENTER button to complete the storage process.
To recall a setup:
1. Press the RCL button.
2. Press the number button (1 to 9) for the configuration to be recalled. (RCL 0 returns the
instrument to the factory default setup.)
3. Press the ENTER button.
Whenever a setup is recalled, the high voltage is turned off for safety.
If an Err3 (recall error) occurs, the stored setup was lost due to a memory error and must be stored
again using the STO button.
The factory default setup can be recalled by pressing the CLR button while turning on the power or by
recalling setup 0 (RCL 0). The default setup is also recalled after a power-on memory error (Err 1).
The next table lists the factory default setup.
Mode Default setting
Output voltage
0 V
Voltage limit
5000 V
Current limit
5.25 mA
Current trip
5.25 mA
Reset mode
MAN
High voltage
OFF
GPIB address
14
Filter
OFF
